8580 – 8 Row Hill Pro Potato Planter
Have a question, or want a quote? Reach out to us anytime, and we will be happy to assist you.
Get directions
Make a call
Fax us now
Send an email
The Hill-Pro Planter is designed to adjust seamlessly to the contours of the ground, ensuring consistent planting performance on uneven terrain. Its innovative system keeps the planter cups level, preventing seed from falling out prematurely. By maintaining a steady depth for the planting shoes, it ensures each seed is placed at the ideal depth for uniform emergence. This results in a more consistent crop stand and improved yield potential.
Model
Number of Rows: 8
Row Unit Alignment: Inline
Row Spacing: 34", 36" row spacing options
Seed Spacing (mechanical drive): Not Available
Seed Spacing (hydraulic drive): 3 to 20 Inches
Hill Compensation: +/- 15 degrees
Chassis
Hitching Mechanism: Pulled
Depth Wheel Sizes: 11.2/10-24
Gage Wheel Sizes: 20.5/8.0-10 225/75-R15
Rear Axle: Walking beam
Tire Sizes: GLXY, GRAFF XLW TIRES,13.00-24,10 HOLE GLXY, MPC TIRES, 13.00-24, 10 HOLE
Row Unit
Cup Options: 2-3 oz (30 mm - 60mm)
Tractor Requirements
Tractor hp: 220 hp (165kW)
Tractor Hydraulic Requirement per Remote : 8-12 gpm (30-45 l/min)
Required Remotes: 3 to 4
Operating Oil Pressure: 2850 psi (196 bar)
Dimensions
Frame Length: 10' 6"
Frame Width: 26' 7"
Transport Height (Hitch Dependent): 9' to 12' 6"
Filling Height (with/without extension): 8' without hopper extensions 9' with hopper extensions
Standard Hopper Capacity: 160 Sacks (16,000 lbs. without hopper extensions)
Extension Hopper Capacity: 200 Sacks (20,000 lbs. with hopper extensions)
Shipping Dimensions
Estimated Shipping Weight: 22,000lbs
Use this Seed Spacing Calculator to determine the required seed spacing or seed required in lbs/acre.
